PETRO 316 Stainless Steel Spring Check Valve

PETRO Spring Check Valve 2 Piece - 316 Stainless Steel

316 Stainless Steel Full Port Spring Loaded Check Valve, 800 WOG c/w PTFE Seat. FEATURES: Soft PTFE seat for bubble tight shutoff, spring loaded for fast seating action. Low cracking pressure, 0.5 psi. Flow profile designed to minimise head loss. Perfect seating both at high...
Fuel tank hire

Request a Quote

Description

316 Stainless Steel Full Port Spring Loaded Check Valve, 800 WOG c/w PTFE Seat.

FEATURES:

  • Soft PTFE seat for bubble tight shutoff, spring loaded for fast seating action.
  • Low cracking pressure, 0.5 psi.
  • Flow profile designed to minimise head loss.
  • Perfect seating both at high and low pressure, wide temperature range: +10° to 450° F.
  • Corrosion resistant—excellent for use on chemicals.
  • ASTM-A351-CF8M investment casting.
  • Connection: FBSP x FBSP.
  • 125WSP saturated steam.
  • ANSI B1.20.1 threads.
  • Dual guided stem & disc.

Size Range:

  • 8mm (1/4”)
  • 10mm (3/8”)
  • 15mm (1/2”)
  • 20mm (3/4”)
  • 25mm (1”)
  • 32mm (1 1/4”)
  • 40mm (1 1/2”)
  • 50mm (2”)
