CARTER Bottom Load Adaptors - 6958BCH & 61528-B

Carter
SKU: 64040
$ POA

📞 Call for A Quote!
Trust Badge

CARTER Bottom Load Adaptors - 6958BCH & 61528-B

Carter 2.-inch aircraft standard bayonet refuelling adapters mate underwing nozzles or 2.-inch hydrant couplers, with several choices of flanged or threaded inlets. These adapters are designed to be used for bottom loading of a re-fueller, for connection to a hydrant system or tank farm pumping system for test adapters, or for use in a recirculation test system on re-fuellers.

FEATURES:

  • They are also available as a stand alone module without a housing.
  • Carter offers a choice of either outlet flanges or TTMA flanges for the three and four inch styles. & nbsp.
  • The 2.5” outlet styles are available only in threaded connections, either NPT or BSPP.
  • The ANSI type flanged units are most suited for hydrant applications while the TTMA units  are suited for bottom loading or recirculation systems.
  • The 2.5” units are (by choosing the correct unit) usable in either application.
  • Product Selection units available.
  • Plastic or military metal sealing caps available.
  • Convenient bosses to mount pressure gauges or sampling ports standard.
  • Pressure equalisation valve offered in poppet for hydrant applications.

PRODUCT RANGE:

Code

Description

Weight

64040

3” 150 lb. ANSI Flat Faced Flange x 2.5” Bayonet (Bottom Loading only)

2.04 kg

61409

4” 150 lb. ANSI Flat Faced Flange x 2.5” Bayonet (Bottom Loading only)

3.3 kg

61272

4” TTMA Flange x 2.5” Bayonet (Bottom Loading only)

1.8kg



ORDERING DATA:

Model 6958-BCH

Option

Description

Weight

2½-inch outlet x 2½-inch bayonet



No product selection –



Use for bottom loading or

recirculation only

A

Adds pressure dust cap

1.315 kg

B

Adds plastic dust cap

*C

Commercial MS24484-2 adapter

*D

Mil-Spec MS24484-5 adapter

*G

Adds 2½-inch - 8 NPT female outlet

*H

Adds 2½-inch BSPP female Outlet

* Options C or D & G or H must be specified to achieve a completed part number

Model 61528-B

3-inch TTMA flange x 2½-inch

bayonet



No product selection –



Use for bottom loading only

A

Adds pressure dust cap

1.497 kg

B

Adds plastic dust cap

*C

Commercial MS24484-2 adapter

*D

Mil-Spec MS24484-5 adapter

* Options “C” or “D” must be specified to achieve a completed part number



Contact PETRO industrial's team of bulk fuel storage and dispensing specialists for more information today!
