GRACO 3:1 Mini Fire-Ball 225 Pump Range
Typical applications are continuous duty, maintenance facility dispensing motor oil, gear oil, automatic transmission fluid, hydraulic fluid.
FEATURES:
- In-line design with fewer parts for less pump wear.
- Differential air motor ensures smooth pumping.
- Double-acting pump provides reliable fluid flow.
- Thick cast aluminium air motor housing for unmatched durability.
- Corrosion resistant design extensively utilises liquid salt nitriding, nickel plating and chrome on key components.
- Precision ground induction hardened displacement rod for minimal wear.
- Guided inlet check valve for superior priming.
- Non-corrosive design (metal parts made of SST, aluminium and chrome) for long life.
- No metal-to-metal contact ā longer pump life.
- Open exhaust port provides continuous operation without icing.
SPECIFICATIONSĀ & PERFORMANCE:
- Cycles per Gallon: 43.5 (11.4 liters)
- Fluid Flow gal/min @ 80 cpm: 1.84 (7.0 liters)
- Maximum Fluid Pressure: 540 psi (37 bar)
- Air Motor Effective Diameter: 2.25 in (57.2 mm)
- Air Operating Range: 40-180 psi (2.8-12 bar)
- Approx. Air Use and Flow @ 100 psi and 80 cpm: 8.5 scfm @ 2.1 gpm, (0.241 m3/min @ 7.9 lpm)
- Wetted Materials: Steel, Buna-N, Polyurethane, Aluminum, RulonĀ®
- Annual Usage: Up to 35,500 gal (132,000 l)
- Line Length: Up to 250 ft (76.2 m)
- Air Inlet Port Size: 3/8 in npt(f)
- Fluid Inlet Port Size: 1-1/2 in npt(f)
- Fluid Outlet Port Size: 1/2 in npt(f)
- Dispense Points: 1 to 2
Mini Fire-Ball 225 & Fire-Ball 300 ā Ordering Information:
|
Packages
|
Portable
|
Cover-Mounted
|
Bung-Mounted
|
Universal
|
|
Container Size
|
16 gal (60 l)
|
55 gal (200 l)
|
275 gal (1040 l)
|
Universal
|
|
Mini Fire-Ball 225,
3:1 Package
|
246903 (4)
|
246904 (4)
|
246906 (4)
|
246907 (3), (4)
|
248230 (3), (4)
|
|
Mini Fire-Ball, 225
3:1 Pump
|
248097 (1), (3)
|
246775
|
|
Fire-Ball 300,
5:1 package
|
225728 (2), (4)
|
225094 (3), (4)
|
225642 (3), (4)
|
225640 (3), (4)
|
225931 (3), (4)
|
225852 (3), (4)
|
|
Fire-Ball 300
Pump
|
203872
|
203857
|
204254
|
222087
|
203876
|
|
Dispense/Hose
Fitting Kit
|
237075
|
222063
|
222062
|
|
Fluid Hose
|
6 ft x 1/2 in
(1.8 m x 12.7 mm)
|
1.5 ft x 1/2 in
(0.5 m x 9.5 mm)
|
|
Air Hose
|
ā
|
6 ft x 3/8 in
(1.8 m x 9.5 mm)
|
1.5 ft x 3/8 in
(0.5 m x 9.5 mm)
|
|
Air Regulator
|
224512
|
ā
|
ā
|
ā
|
|
Cover
|
204574
|
200326
|
ā
|
ā
|
ā
|
|
Caster Base
|
203622
|
ā
|
ā
|
ā
|
ā
|
ā
|
|
Bung Adapter for
300, 5:1
|
ā
|
ā
|
ā
|
222308
|
ā
|
|
225, 3:1 Manual
|
309868
|
|
300, 5:1 Manual
|
307884
|
307883
|
306520
|
Ā (1) 248097 includes suction tube (15C502) and bung adapter (222308)
(2) Use 3/8 in (9.5 mm) installation kit (224512) as required
(3) Use 3/8 in (9.5 mm) air regulator 109075 as required; must be ordered separately
(4) Order low-level cut-off 203688 (1 1/2 inch NPT) separately for metered dispense systems
Ā
Mini Fire-Ball 225, 3:1 Pump Packages:
|
Code
|
Description
|
|
248623*
|
Includes: Mini Fire-Ball 225, 3:1 Universal pump with bung adapter and down tube (248097), SD Series reel with 50 ft (15.2 m) x 1/2 in (12.7 mm) fluid hose (HPM65B), LDM5 meter (256215)
|
|
248622*
|
Includes: Mini Fire-Ball 225, 3:1 Universal pump with bung adapter and down tube (248097), SD Series reel with 25 ft (7.6 m) x 1/2 in (12.7 m) fluid hose (HPM33B), LDM5 meter (256215)
|
Ā * Order 218549 (1/2 in x 24 in) hose reel inlet kit separately NOTE: Tanks not included.
Ā
Fire-Ball 300, 5:1 Pump Packages:
|
Code
|
Description
|
|
241633*
|
Includes: Fire-Ball 300, 5:1 pump universal (203876), 3/8 in (9.5 mm) regulator/gauge (109075), 3/8 in (9.5 mm) x 3/8 in (9.5 mm) nipple (156849), 2 in (50.8 mm) bung adapter (222308), SD Series reel with 25 ft (7.6 m) x 1/2 in (12.7 mm) hose (HPM33B), SDM5 meter (255350)
|
|
224541*
|
Includes: Fire-Ball 300, 5:1 pump universal (203876), 3/8 in (9.5 mm) regulator/gauge (109075), 3/8 in (9.5 mm) x 3/8 in (9.5 mm) nipple (156849), 2 in (50.8 mm) bung adapter (222308), SD Series reel with 50 ft (15.3 m) x 1/2 in (12.7 mm) hose (HPM65B), 18 in (45.7 cm) hose (220598), 90Āŗ swivel (inlet on hose reel) (157416), SDM5 meter (255350)
|
|
244038*
|
Includes: Fire-Ball 300, 5:1 pump universal (203876), 3/8 in (9.5 mm) regulator/gauge (109075), 3/8 in (9.5 mm) x 3/8 in (9.5 mm) nipple (156849), 2 in (50.8 mm) bung adapter (222308), SD Series reel with 50 ft (15.3 m) x 1/2 in (12.7 mm) hose (HPM65B), 18 in (45.7 cm) hose (220598), 90Āŗ swivel (157416), SDP5 meter (255200)
|
|
224534*
|
Dispensing from Bench-Top Tanks with Fire-Ball 300, 5:1 Pump Package. Includes: Fire-Ball 300, 5:1 pump, Universal (203876), 3/8 in (9.5 mm) regulator/gauge (109075), Air filter (106148), 3/8 in (9.5 mm) x 3/8 in (9.5 mm) nipple (156849), SD Series reel with 50 ft (15.3 m) x 1/2 in 12.7 mm) hose (HPM65B), Drain valve (106151), 72 in (182.9 cm) hose kit (222063), Thermal relief valve (237893), 90Āŗ swivel (157416), SDM5 Meter (255350)
|
Ā * Order 218549 (1/2 in x 24 in) hose reel inlet kit separately NOTE: Tanks not included.
